F9500 Series Channel Penstock, 3-Sides-Sealing Type
■ General Information
■ Fields Of Application
Keywords:
Channel Penstock
Sluice Gate
Slide Gate
Product Series:
■ Unique Design
Compact integral frame profile, less welding happen on frame
Modular concept, penstock is suitable for square, rectangle and round passageway
Door rail from top to bottom, the door will never touch the frame, reduces the operating torque
All penstocks are standard On-Off seating, and 3-Sides-Sealing Type
When door at partial opening position, the water will only get through the opened passageway, suitable for throttling and regulating application
NRS or RS spindle is available
■ Operation
■ Mounting Type
■ Materials
| Parts | Materials |
|---|---|
| Frame | Stainless Steel：ANSI SS304, SS316L, DIN EN 10088-3 1.4301, 1.4401, 1.4571；Duplex Stainless Steel: SAF 2205, SAF2507 |
| Door | Stainless Steel：ANSI SS304, SS316L, DIN EN 10088-3 1.4301, 1.4401, 1.4571；Duplex Stainless Steel: SAF 2205, SAF2507 |
| Spindle | Stainless Steel：ANSI SS304, SS316L, DIN EN 10088-3 1.4301, 1.4401, 1.4571；Duplex Stainless Steel: SAF 2205, SAF2507 |
| Headstock, Handwheel | CS With Epoxy Coating, Stainless Steel ANSI SS304, SS316L |
| Door Rail | POM. UHMWPE |
| Spindle Nut | Aluminum Bronze |
| Profile Seal | EPDM, NBR, VITON |
| Fastener | Stainless Steel：A2-70, A4-70; Duplex Steel: S31803 |
Product Series
■ Our Valves
F9000 Series Square Penstock, 4-Sides-Sealing Type
Design Standard：BS7775, 4-Sides-Sealing Type Testing Standard：BS7775 Sizes：200X200-3000X3000mm Working Head: On / Off Seating, Max. 4/6/10m W.C. Mounting: Wall Mounting
F9010 Series Weir Penstock, 4-Sides-Sealing Type, Downward Opening
Design Standard：BS7775, 4-Sides-Sealing Type, Downward Opening Testing Standard：BS7775 Sizes: 200X200-3000X3000mm Working Head: On/Off Seating, Max. 4m W.C. Mounting: Wall Mounting
F9060 Series Isolating Flushing Penstock
Design Standard: Manufacturer's Standard, 4-Sides-Sealing Type Testing Standard：BS7775 Wall Mounting One Actuator Drives One Penstock, or One Actuator Drives Two Penstocks Sizes: 1500X150 - 4000X200
F9500 Series Channel Penstock, 3-Sides-Sealing Type
Design Standard：BS7775, 3-Sides-Sealing-Type Testing Standard：BS7775 Sizes：200X200-3000X3000mm Mounting: Channel mounting, Wall Mounting
