F2600 Series Rubber-Lined Butterfly Valve

■ General Information

Design Standard: API609 / EN593 Testing Standard: API598 / DIN EN12266-1 Sizes: 1.5”-40” / DN40-DN1000 Pressure Rating: 150 PSI / 200 PSI, PN6 /PN10 / PN16 Connecting Ends：Wafer / Lug / Double Flanges, Multi-Drilled To EN1092 PN10/16 & ANSI B16.5

■ Fields Of Application

Water Supply Sewage Oil Steam

Keywords:

Rubber-Lined Butterfly Valve

Centric-Disc Type Butterfly Valve

Inquiry

Product Series:

Butterfly Valve-Centric Disc Type

■ Unique Design

Centric-Disc-Type, low operating torque
No-pin between shaft and disc
Steam-line passageway, low headloss
Shaft Blow-Out-Prevention design
Replaceable seat for Bi-direction seal
Seat with integral hard back to prevent rubber leaves it position
International standard square shaft, integral ISO5211 flanges
Body is internal and external coated with epoxy resin powder

■ Various Opeartion Type

★ Special operating type request, please contact our engineer

■ Materials

Parts	Materials
Body	Cast Iron：GG25 （DIN1639）, ASTM A126 CLASS B
	Ductile Iron：GGG40 (DIN1639), ASTM A536 GR.65-45-18
	Cast Steel：WCB (ASTM A216)
	Stainless Steel：CF8, CF8M, CF3M (ASTM A351)
Disc	DI Nickel Plated, DI with Epoxy Coating or Nylon Coating
	Stainless Steel：ASTM A351 CF8, CF8M (ASTM A351)
	Duplex Stainless Steel：1.4410, 1.4529
	Aluminum Bronze：C95400, AB1, AB2
Seat	NBR, EPDM, SI-RUBBER. VITON, PTFE
Bushing	PTFE，Aluminum Bronze（only for size DN600 and above)
Shaft	Stainless Steel：SS410, 17-4PH, SS304, SS316 (ASTM A476)
Shaft Retaining Plate	Stainless Steel SS201, SS304, SS316,SS316L
Fastener	A2-70, A4-70
Opeating Units	Handle：Ductile Iron with Epoxy Coating, Aluminum With Epoxy Coating
	Gear Box：Cast Iron, Ductile Iron, WCB, Stainless Steel, or Aluminum ( only for size upto DN300)

None

Product Series

■ Our Valves

F9000 Series Square Penstock, 4-Sides-Sealing Type

Design Standard：BS7775, 4-Sides-Sealing Type Testing Standard：BS7775 Sizes：200X200-3000X3000mm Working Head: On / Off Seating, Max. 4/6/10m W.C. Mounting: Wall Mounting

F9010 Series Weir Penstock, 4-Sides-Sealing Type, Downward Opening

Design Standard：BS7775, 4-Sides-Sealing Type, Downward Opening Testing Standard：BS7775 Sizes: 200X200-3000X3000mm Working Head: On/Off Seating, Max. 4m W.C. Mounting: Wall Mounting

F9060 Series Isolating Flushing Penstock

Design Standard: Manufacturer's Standard, 4-Sides-Sealing Type Testing Standard：BS7775 Wall Mounting One Actuator Drives One Penstock, or One Actuator Drives Two Penstocks Sizes: 1500X150 - 4000X200

F9500 Series Channel Penstock, 3-Sides-Sealing Type

Design Standard：BS7775, 3-Sides-Sealing-Type Testing Standard：BS7775 Sizes：200X200-3000X3000mm Mounting: Channel mounting, Wall Mounting
